Satellite Applications
Raltron’s satellite timing and RF portfolio delivers the precision, stability and reliability demanded by today’s GNSS, TT&C and broadband space applications. Manufactured in their Miami, FL facility, Raltron OCXOs provide ultra-stable, low phase noise frequency references from 10 MHz to 100 MHz for demanding RF, microwave, and timing architectures. Raltron VCXOs, TCXOs and Monolithic Crystal filters provide the ultra‑stable, finely tunable frequency references and high‑selectivity RF filtering needed to meet demanding satellite communication and GNSS performance requirements.
Radiation-Hardened
Low Phase Noise OCXO
Raltron’s OCXOs deliver excellent frequency stability with very low phase noise and clean sinewave output for high-performance RF, radar, and test systems.
View Low Phase Noise OCXO Flyer
Part Number | ECAD | Datasheet | Image | Frequency (MHz) | Size (mm) | Output | Supply Voltage (V) | Stability (ppb) | Package | RoHS | REACH | Conflict Materials | Contact Us / Buy Now |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
 |
100
|
25.4 x 25.4 |
SINE WAVE |
12 |
±200 |
TH |
High Performance OCXO
OXH series OCXOs offer ppb-class stability, low close-in phase noise, and controlled thermal behavior for demanding synthesizers, converters, and microwave test equipment.
View High Performance OCXO Flyer
Part Number | ECAD | Datasheet | Image | Frequency (MHz) | Size (mm) | Output | Supply Voltage (V) | Stability (ppb) | Package | RoHS | REACH | Conflict Materials | Contact Us / Buy Now |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
10
|
25.4 x 25.4 |
SINE WAVE |
12 |
±5 |
TH |
LEO Space OCXO
Raltron’s LEO Space OCXOs combine exceptional frequency stability, ultra-low phase noise, and radiation-tolerant construction for satellite payloads and precision timing in low Earth orbit.
Part Number | ECAD | Datasheet | Image | Frequency (MHz) | Size (mm) | Output | Supply Voltage (V) | Stability (ppb) | Package | RoHS | REACH | Conflict Materials | Contact Us / Buy Now |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
 |
10
|
25.4 x 25.4 |
CMOS |
5.0 |
±500 |
TH |
||||||
|
|
100
|
25.4 x 25.4 |
CMOS |
5.0 |
±500 |
TH |
Non Radiation-Hardened
Low Power OCXO
The OXL low-power OCXO series provides low phase noise and good stability with significantly reduced power in compact DIP and SMD packages for portable RF and instrumentation designs.
TCXOs
Raltron TCXOs provide compact, low‑power crystal references with excellent temperature stability for precise satellite communication and GNSS timing.
Product Series | ECAD | Datasheet | Image | Frequency (MHz) | Size (mm) | Output | Supply Voltage | RoHS | REACH | Conflict Materials | Contact Us / Buy Now |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
 |
10~52
|
5.0 x 3.2 |
CLIPPED SINE ⋅ CMOS |
3.3 |
||||||
|
 |
10~52
|
5.0 x 3.2 |
CLIPPED SINE ⋅ CMOS |
3.3 |
||||||
|
 |
10~52
|
7.0 x 5.0 |
CLIPPED SINE ⋅ CMOS |
3.3 |
||||||
|
 |
10~52
|
7.0 x 5.0 |
CLIPPED SINE ⋅ CMOS |
3.3 |
VCXOs
VCXOs offer finely tunable crystal references that maintain tight frequency and phase alignment in satellite and GNSS systems.
View High Frequency VCXO Flyer
Part Number | ECAD | Datasheet | Image | Mounting | Frequency (MHz) | Size (mm) | Output | Supply Voltage (V) | Stability (ppm) | Temperature Range (°C) | Voltage Control | Contact Us / Buy Now |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
 |
Surface Mount |
100.00 |
14.3 x 9.0 |
SINE WAVE |
5.0 |
±20 |
-40~85 |
YES |
Monolithic Crystal Filters
Monolithic Crystal Filters deliver high‑Q, narrowband RF and IF filtering with sharp selectivity and low insertion loss for satellite receivers and transceivers.
Part Number | ECAD | Datasheet | Image | Frequency (MHz)
| Size (mm) | Application | Pass Band (kHz) | Insertion Loss (dB) | Guaranteed Attenuation (dB) | RoHS | REACH | Conflict Materials | Contact Us / Buy Now |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
 |
100.000 |
6.0 x 3.5 |
LEO |
±10.0 |
4.0 |
65 |
||||||
|
 |
150.000 |
7.0 x 5.0 |
LEO |
±7.5 |
4.0 |
45 |
