XCO-Fast Delivery Programmable Clock Oscillators
The Raltron XCO Series of programmable clock oscillators ships in 1-2 weeks and are available with LVCMOS, LVDS or LVPECL outputs for frequency applications ranging from 10-250 MHz.
If you do not find the exact solution in the product information below, please let us know and we can create it for you.
1-2 Weeks for up to 5K Pieces
Send your XCO RFQs directly to xco@raltron.com or call us at +1-305-593-8000
Send your XCO RFQs directly to xco@raltron.com or call us at +1-305-593-8000
Fast Delivery Programmable Clock Oscillator Products
Filters
Sort results
Reset
Apply
Product Series | ECAD | Datasheet | Image | Frequency (MHz) | Size (mm) | Output | Supply Voltage (V) | RoHS | REACH | Conflict Materials | Contact Us / Buy Now |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
 |
10~250
|
3.2 x 2.5 |
CMOS |
2.5 ⋅ 3.3 |
||||||
|
 |
10~1200
|
3.2 x 2.5 |
LVDS |
2.5 ⋅ 3.3 |
||||||
|
 |
10~1200
|
3.2 x 2.5 |
LVPECL |
2.5 ⋅ 3.3 |
||||||
|
 |
10~250
|
5 x 3.2 |
CMOS |
2.5 ⋅ 3.3 |
||||||
|
 |
10~1200
|
5 x 3.2 |
LVDS |
2.5 ⋅ 3.3 |
||||||
|
 |
10~1200
|
5 x 3.2 |
LVPECL |
2.5 ⋅ 3.3 |
||||||
|
 |
10~250
|
7 x 5 |
CMOS |
2.5 ⋅ 3.3 |
||||||
|
 |
10~1200
|
7 x 5 |
LVDS |
2.5 ⋅ 3.3 |
||||||
|
 |
10~1200
|
7 x 5 |
LVPECL |
2.5 ⋅ 3.3 |
